用于细胞和细胞簇的重找回
便于进行固定区域的细胞计数
玻璃底可用于TIRF和单细胞应用
应用：
重新定位细胞和细胞簇，如转染细胞的克隆挑选
对某一划定区域的细胞计数，如计算转染效率
为细胞运动提供一个参考结构
独特的单个细胞处理，如显微注射
| 货号 | 产品名称 | 规格（个/盒） |
| 81148 | μ-Dish 35 mm,高壁，玻璃底，50微米格子培养皿 | 30 |
| 81168 | μ-Dish 35 mm,高壁，玻璃底，500微米格子培养皿 | 30 |
| 80156 | μ-Dish 35 mm,低壁，ibiTreat底部处理，500微米格子培养皿 | 60 |
| 80151 | μ-Dish 35 mm,低壁，无包被，500微米格子培养皿 | 60 |
| 81166 | μ-Dish 35 mm,高壁，ibiTreat底部处理，500微米格子培养皿 | 60 |
| 81161 | μ-Dish 35 mm,高壁，无包被，500微米格子培养皿 | 60 |
技术特征：
底部50μm网格
字母和数字标识的4 x 400 个方格（A-U; 1-20）
网格和细胞在一个焦面
底部为D 263 M肖特玻璃，厚度为170 μm +/- 10 μm
盖子有锁扣设计，可以减少蒸发
产品规格：
| Grid repeat distance | 50 μm | Coating area using 400 μl | 4.1 cm2 |
| ? μ-Dish | 35 mm | ? observation area | 21 mm |
| Volume | 2 ml | Height with / without lid | 14/12 mm |
| Growth area | 3.5 cm2 | Bottom | Glass coverslip No. 1.5, selected quality, 170 μm +/- 10 μm |
| Optical properties | ||
| Refractive index (nD 589 nm) | 1.52 | 1.52 |
| Abbe number | 56 | 55 |
| Thickness | #1.5 (180 μm) | #1.5 (170 μm) |
| Material | Microscopy plastic | D 263M Schott borosilicate glass |
| Autofluorescence | Low | Low |
| Transmission | Very high (even ultraviolet) | High (ultraviolet restrictions) |
| Birefringence (DIC) | Low (DIC compatible*) | Low (DIC compatible*) |
| Other aspects | ||
| Surface modifications | ibiTreat – tissue culture treated Uncoated – hydrophobic | Only pure glass |
| Protein coatings | Possible | Possible |
| Gas permeable | Yes | No |
| Material flexibility | High | Low |
| Breakable | No | Yes |
| Recommended for | All kinds of fluorescence microscopy | TIRF and single photon |
